[ A3 Color Digital MFP ] D311
Total solution for smart users Sindoh A3 Color MFP
[ A3 Color Digital MFP ] D311

Total solution for smart users Sindoh A3 Color MFP

D311

COPY
  1. Speed

    Color : 28 ppm
    Black and White : 28 ppm

  2. Preheating time

    Less than 20 seconds

  3. First page c opy speed

    Color : Less than 8.4 seconds
    Black and White : Less than 6.8 seconds

  4. Print resolution

    Up to 1,800 (E quivalent) x 600 dpi

  5. Processor

    ARM Cor tex-A7 Dual Cor e 1.2 GHz

  6. Memory

    2 GB (std.) 4 GB (max.)

  7. HDD

    250 GB

  8. Duplex print

    Standard

  9. Max power consumption

    Less than 1.6 kw

  10. Noise

    In printing : Less than 66dB
    In stand-by : Less than 46dB

  11. Display

    7-inch Color LCD

  12. Size (W x D x H)

    585 x 700 x 906mm (MFP + RADF)

  13. Weight

    82Kg (MFP + RADF)

SCAN
  1. Scan mode

    Color, Gray Scale, Black and White

  2. Speed(at 300 dpi, color / Black and White)

    45 / 45 ipm (A4 / RADF)

  3. Resolution

    Push : 200 / 300 / 400 / 600 dpi
    Pull : 100 / 200 / 300 / 400 / 600 dpi

  4. Interface

    10Base-T / 100Base-TX / 1000Base-T

  5. Protocol

    TCP / IP (FTP, SMB, SMTP, WebDAV) (IPv4 / IPv6)

  6. OS compatible

    Windows Vista / Vista (x64) / 7 / 7 (x64) / 8 / 8 (x64) / 8.1 / 8.1 (x64) / 10

  7. Support format

    TIFF, JPEG, PDF, Compact PDF, OOXML (pptx, docx, xlsx), XPS, Compact XPS, Searchable PDF, PDF/A, Linearised PDF

PRINT
  1. Speed

    Color : 28 ppm
    Black and White : 28 ppm

  2. Resolution

    Up to 1,800 x 600 dpi

  3. Emulation

    PCL5e/c, PCL6, PostScript3, XPS ver 1.0

  4. OS compatible(PCL)

    Windows Vista / Vista (x64) / 7 / 7 (x64) / 8 / 8 (x64) / 8.1 / 8.1 (x64) / 10 / WindowsServer 2008 / 2008 (x64) / 2008 R2 / 2012 / 2012 R2

  5. OS compatible(PS)

    Windows Vista / Vista (x64) / 7 / 7 (x64) / 8 / 8 (x6 ) / 8.1 / 8.1 (x64) / Windows Server 2008 / 2008 (x64) / 2008 R2 / 2012 / 2012 R2 / MacOSX (10.6 / 10.7 / 10.8 / 10.9 / 10.10)

  6. OS compatible(XPS)

    Windows Vista / Vista (x64) / 7 / 7 (x64) / 8 / 8 (x64) / 8.1 / 8.1 (x64) / Windows Server 2008 / 2008 (x64) / 2008 R2 / 2012 / 2012 R2

  7. Memory

    2 GB

  8. Interface

    Ethernet 10Base-T / 100Base-TX / 1000Base-T / USB 2.0 (High-Speed) / 1.1

FAX (option)
  1. Communication lines

    PSTN (Public Switch Telephone Network), PBX (Private Branch Exchange), G3 (Fax line)

  2. Tx speed

    2.4 ~ 33.6 kbps

  3. Tx time

    3 second or less (A4, V.3 4, 33.6 kbps, JBIG)

  4. Data compression type

    MH, MR, MMR, JBIG

  5. Communication mode

    ECM / G3

  6. Tx size

    Flat Bed : Width 297 x length 431.8 mm (A3 or 11" x 17")
    RADF : Width 297 x length 1,000 mm

Paper
  1. Paper Feed

    Standard Tray : 1,000 sheets (500 sheets x 2-sets, 80 g/㎡)
    Multi-purpose tray : 100 sheets (80 g/㎡)
    RADF : 100 sheets (80 g/㎡)

  2. Size

    Standard Tray 1 : A5 ~ B4, 5.5" x 8.5" ~ 8.5" x 14"
    Standard Tray 2 : A5 ~ A3, 5.5" x 8.5" ~ 11" x 17"
    Multi-purpose tray : A6 ~ A3, 5.5" x 8.5" ~ 11" x 17"

  3. Weight

    Standard Tray : 60 ~ 256 g/㎡
    Multi-purp ose tray : 60 ~ 256 g/㎡
    RADF : Thin Paper 35 g/㎡ ~ 49 g/㎡ (single-sided), Plain Paper 50 g/㎡ ~ 128 g/㎡ (single-sided/Duplex)

  4. Output Tray

    250 sheets

Consumables
  1. Toner

    Black and White : 24,000 sheets
    Color : 21,000 sheets
